Applications
Weighing, Parts Counting, Percent Weighing
Display
Backlit liquid crystal display (LCD)
Operation
AC adapter (included)
Communication
RS232 (included)
Construction
Metal base, ABS top housing, stainless steel pan, glass draftshield with sliding top door (1mg models only), up-front level indicator, integral weigh below hook, security bracket, calibration lock, in-use cover
Design Features
Selectable environmental filters, auto tare, software lockout and reset menu, user selectable communication and printing settings
| Maximum Capacity |
810 g |
| Readability |
0.01 g |
| Readability (Certified) |
0.1 g |
| Pan Size |
7.1 in x 6.1 in (180 mm x 168 mm) |
| Battery Life |
Not Applicable |
| Communication |
RS232 (Included) |
| Auxiliary Display Model |
Available as an Accessory |
| Dimensions |
12.6 in x 3.8 in x 7.7 in (320 mm x 96 mm x 196 mm) (LxHxW) |
| Display |
LCD with backlight |
| Internal Calibration |
Not Applicable |
| In-Use Cover |
Included |
| Legal for Trade |
NTEP Certified; Measurement Canada Approved |
| Linearity ± |
0.02 g |
| Net Weight |
7.7 lb (3.5 kg) |
| Pan Construction |
Stainless Steel |
| Power |
AC Adapter (Included) |
| Repeatability, typical |
0.01 g |
| Stabilization Time |
3 s |
| Tare Range |
To capacity by subtraction |
| Transportation Case |
No |
| Units of Measurement |
Milligram; Pennyweight; Ounce Troy; Gram; Grain; Ounce; Carat |
| Working Environment |
50°F – 104°F, 80%RH, non-condensing (10°C – 30°C, 80%RH, non-condensing) |
